DESCRIPTION AND USE
Self priming centrifugal electric pumps made in bronze ( slow priming) capable of transfer or supply large flow of liquid. They are widely used in the nautical sector to empty bilges, fire-fighting equipment, ballast, washing of decks and chains and air conditioning systems. The particular impeller shape allows the transferring of liquid with small solid parts in suspension.
CONSTRUCTION FEATURES
Pump body: BRONZE
Motor support: BRONZE
Impeller: BRONZE
Shaft : AISI 316 STAINLESS STEEL
Mechanical seal: CERAMICS – GRAPHITE – NBR (special corrosion-proof)
MOTOR
Direct Current:
Permanent magnets electric motor 12/24V, Protection IP23, Insulation Class F, Continuous Duty (S1).
Alternate Current:
Induction electric motor, 230V single-phase (M) / 230÷400V or 400÷690V three-phase (T), 50Hz, Protection IP55, Insulation Class F, Continuous Duty (S1).
SCOPE
Solid parts handling (max. Ø) :
AM40: 4,5 mm / AM50: 8 mm / AM65-AM65/1: 14 mm / AM512: 10 mm / AM615: 15 mm / AM810: 15 mm
Temperature range of the liquid: from +0 to +70°C
Max. suction depth:
AM40: 4,5m. / AM50:5,5 m / AM65: 7,5 m
AM512, AM615 e AM 801: 6 m
Static pressure inside the pump body: 6 bar max.
ACCESSORIES ON REQUEST
Threaded counter flanges made in bronze for AM40, AM50, AM65, AM65/1
Omega base with antivibrations
PERFORMANCES
24V: DIRECT CURRENT
230M, 50Hz: single-phase alternate current
230÷400T / 400÷690T, 50Hz: three-phase alternate current
Available on request other voltages at 50Hz and 60Hz.
